Data Compression
Implements differential Huffman encoding in accordance with the ITU-T.81 JPEG standard, offering a simple yet robust solution for lossless image compression in space applications. The architecture is optimized for radiation resilience and can be easily hardened using Triple Modular Redundancy (TMR) with minimal utilization overhead — ensuring reliable, fault-tolerant data handling in orbit.
Lossless image compression
Supported color depths
up to 16 bits
Supported planar or interleaved data compression
up to 4 planes
Highly condfigurable IP cores
Depending on desired use case, IP can be configured to minimize resource utilization on FPGA
Hardware
Not dependent on FPGA vendor
Example
Uncompressed RGB888 9.85 MB
Lossless RGB888 6.79 MB (31.07% Less)
Lossy RGB888 2.46 MB (75.03% Less)
Have a unique mission requirement?
Go beyond off-the-shelf solutions. Our core expertise lies in the end-to-end engineering of custom optical payloads. From optical design and sensor integration to flight-ready hardware, we also build instruments precisely tailored to your mission goals and requirements.
